i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04
- -226
6.2.2 Searching for a Hard Disk File
To display a list of files stored on the data server board built-in hard
disk, select the first file by specifying its number or name.
Procedure
1 Display the Hard Disk File Directory screen.
2 Press the operation menu key at the end of the soft key menu.
3 Press soft key [SRCH FILE].
4 Using the MDI keys, enter the number or name of the file to be
searched for. Alternatively, select this file using the cursor.
[Input format]
<file-number>, <file-name>, or <cursor>
5 Press soft key [EXEC].
6 During search, SRCH blinks at the top of the screen.
NOTE
1 If the specified file does not exist on the data server
board built-in hard disk, a file list appears, in ASCII
character order of file names, using the file following
the specified file as the first.
2 The data server functions contain the FTP server
function. As a result, the following may occur without
being noticed by an operator: a new file is transferred
to the data server board built-in hard disk or the file
for which a search was being made is deleted. So,
the file number indicating the specified file may be
changed without being noticed by the operator.
When specifying the file number, check the file name
before operation.
