2.SETTING V. CONNECTION B-63354EN/04
- -294
CAUTION
Even if a control unit is installed in the environment
described above, the contents on the hard disk or
ATA flash card may be destroyed as a result of a
misoperation or unexpected event. This tends to
happen if the power is turned off while accessing the
hard disk or ATA flash card. Therefore, never turn off
the power while the disk or card is being accessed.
Make a backup of data on the hard disk or ATA flash
card to guard against data loss.
NOTE
On vibrations
Resonance of the hard disk drive unit installed in the
cabinet may occur at a certain frequency.
Ensure that the hard disk drive unit is securely
installed in the machine.
