4.16i/18i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04

- -124

Restrictions on file names in the list file

The following restrictions apply when file names are specified in the

list file.

<1> Only the following 76 different ASCII characters can be used in

arbitrary file names.

Digits 0 to 9

Lowercase letters a to z

Uppercase letters A to Z

14 different special characters . (period), ! , #, $, %, &, -, @, ^, _,

', {, }, and ~

This restriction applies also when the name of a file held on the

host computer built-in hard disk is specified.

<2> The arbitrary file name can be up to 255 characters. If an attempt

is made to specify a larger arbitrary file name, an error is detected.

<3> Any file to be used on the data server board built-in hard disk must

be in the 8.3 format. If an "arbitrary" file name is not in the 8.3

format, it is converted to an 8.3-format file name automatically

according to the following rule:

- If the first 8 characters in the original "arbitrary" file name

include no period, they are used as the post-conversion file

name. If they include a period, the characters before the

period are used as the post-conversion file name. If the first

3 characters after the period include no period, they are used

as the post-conversion file extension. If they contain periods,

a characters between the first and second periods are used as

the post-conversion file name extension.

Example 1) If the original file name is

"LONGFILENAME.LONGEXT," the post-

conversion file name is: "LONGFILE.LON"

Example 2) If the original file name is

"ABCD.EFGH.TXT," the post-conversion file

name is: "ABCD.EFG"

NOTE

The names of files handled in the data server must be

in the 8.3 format. If "arbitrary" file names are not in

the 8.3 format, they are converted to this format

automatically when they are handled in the data

server. Different "arbitrary" file names may be

converted to the same file name in the 8.3 format;

therefore, they will be regarded as the same file.
