4.16i/18i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04

- -166

4.6 DNC OPERATIONS

DNC operation is performed using an NC program stored on the data

server board built-in hard disk or on the host computer built-in hard

disk.

For DNC operation in storage mode

Procedure

1 Place the CNC in RMT mode.

2 Display the Hard Disk File Directory screen and move to the

directory holding an NC program used to perform a DNC

operation.

3 Press soft key [(OPRT)].

4 Press soft key [DNC SET].

5 Using the MDI keys, enter the file number or file name of the NC

program for which DNC operation is to be executed.

[Input format]

<file-number> or <file-name>

6 Press soft key [EXEC]. The file name of the NC program for

which DNC operation is to be performed is displayed in DNC

FILE NAME in the upper part of the screen.

7 When the cycle start is executed, DNC operation is executed.

CAUTION

For multipath control, DNC operation cannot be

simultaneously executed for two or more paths.

NOTE

DNC operation cannot be executed simultaneously

with NC program input, NC program output, or DNC

operation by a subprogram call (M198).
