B-63354EN/04 III. SETTING 6.DATA SERVER FUNCTIONS FOR THE 15i

- -93

NOTE

1 When the "TCP/IP setting items for the CNC" have

been changed, the power must be turned off then on

again.

2 Note that the system differentiates between upper-

and lower-case characters in "USERNAME" and

"PASSWORD," described under "Setting items for

the FTP server."

3 The default for "LOGIN DIR," described under

"Setting items for the FTP server," is the \NCDATA

directory. Only a directory under the \NCDATA

directory can be specified for "LOGIN DIR."

4 Press soft key [SAVE] to save the parameter settings

into the non-volatile memory of the CNC.
