Ethernet/Data Server Board Operators manual Page 99

Operators manual
B-63354EN/04 III. SETTING 5.FOCAS1/ETHERNET FUNCTIONS FOR THE 15i
- -85
5.3 PARAMETERS
The following describes the parameters related to the
FOCAS1/Ethernet functions.
Parameters
0020 Interface number of input device for foreground
[Input section] Setting input
[Data type] Integer
[Valid data range] 0 to 16
6: Selects the FOCAS1/Ethernet as the I/O device to perform DNC
operation.
7: Selects the FOCAS1/Ethernet as the I/O device.
0021 Interface number of output device for foreground
[Input section] Setting input
[Data type] Integer
[Valid data range] 0 to 16
7: Selects the FOCAS1/Ethernet as the I/O device.
0022 Interface number of input device for background
[Input section] Setting input
[Data type] Integer
[Valid data range] 0 to 16
7: Selects the FOCAS1/Ethernet as the I/O device.
0023 Interface number of output device for background
[Input section] Setting input
[Data type] Integer
[Valid data range] 0 to 16
7: Selects the FOCAS1/Ethernet as the I/O device.
5029 Selects host 2 OS.
[Data type] Byte
[Valid data range] ms
[Valid data range] 0 to 255
Specifies the wait time in ms for each service of the FOCAS1/Ethernet
when it is used together with the data server function.
If a value between 0 and 2 is specified, a wait time of 2 ms is assumed.
NOTE
When the FOCAS1/Ethernet function is used to
download or upload normal NC data, specify 7 as the
I/O device number.
Only when performing DNC operation, specify 6.
