B-63354EN/04 V. CONNECTION 4.HARDWARE CONNECTIONS

- -329

4.4.2 Cable Materials

Unshielded cable (UTP cable) is commercially available as 10BASE-

T twisted-pair cable: You should, however, use shielded Category 5

twisted-pair cable (STP cable) to improve the resistance to electrical

noise in an FA environment.

Recommended Cables

Manufacturer Specification Remarks

Furukawa Electric Co., Ltd. DTS5087C-4P Twisted-pair cable

Nissei Electric Co., Ltd. F-4PFWMF Single-conductor cable

Inquiries

Manufacturer Contact address

Furukawa Electric Co.,Ltd.

Sales Headquarters

2-6-1 Marunouchi, Chiyoda-ku. Tokyo 100-8322

TEL: 03-3286-3126 FAX: 03-3286-3979

Remark

Nissei Electric Co., Ltd.

Machida Branch

3F MU Bldg., 1-9-1 Minami-narise, Machida City,

Tokyo 194-0045

TEL: 0427-29-2531 FAX: 0427-29-3375

Overseas Sales Office IWATANI International Corporation

Tokyo Head Office

21-8 Nishi-shinbashi 3-chome, Minato-ku,

TOKYO, 105-8458, JAPAN

TEL: 03-5405-5810 FAX: 03-5405-5666

Telex: 2524256 IWATYO J

NOTE

The recommended cables cannot be connected to

moving parts.

4.4.3 Connector Specification

Use an 8-pin modular connector (RJ-45) with the twisted-pair cable for

the Ethernet connection. The following connectors or equivalents must

be used.

Specification Manufacturer Remarks

Solid wire 5-569530-3 AMP Japan, Ltd.

Solid wire MS8-RSZT-EMC SK KOHKI Co., Ltd.

Special tools

required

Twisted-pair cable 5-569552-3 AMP Japan, Ltd.

Twisted-pair cable TM11AP-88P Hirose Electric Co.,Ltd.

Special tools

required
