Ethernet/Data Server Board Operators manual Page 253

Operators manual
B-63354EN/04 IV. OPERATION 6.15i
i i
i DATA SERVER FUNCTIONS
- -239
6.2.12 Executing Hard Disk File LIST-DELETE
Delete files from the data server board built-in hard disk according to
the contents of the list file.
Procedure
1 Display the Hard Disk File Dir screen.
2 Press the operation menu key at the right end of the soft key menu.
3 Press soft key [DEL LIST].
4 Enter the name of the list file held on the data server board built-
in hard disk, using the MDI keys.
[Input format]
<number-of-list-file>
or
<name-of-list-file>
or
<Cursor>
5 Press soft key [EXEC].
6 During LIST-DELET operation, " LDEL " blinks in the lower-
right part of the screen.
7 To stop LIST-DELET, press soft key [STOP].
NOTE
1 If an error occurs, check the cause of the error using
the Ethernet Error Message screen.
2 If more than one file is specified to be deleted,
pressing soft key [STOP] before the completion of the
file deletion makes it impossible to restore the
deleted file(s).
3 A method of using a file number to specify a file to be
deleted can be used only for files displayed on the
Hard Disk File Directory screen.
4 See Subsection 5.1.7, "List File Formats," for
explanations about the formats of the list file.
