Ethernet/Data Server Board Operators manual Page 247

Operators manual
B-63354EN/04 IV. OPERATION 6.15i
i i
i DATA SERVER FUNCTIONS
- -233
6.2.8 Moving a Directory on the Data Server Board Built-in Hard
Disk
Move a work directory on the data server board built-in hard disk.
Procedure
1 Display the Hard Disk File Directory screen.
2 Press the operation menu key at the right end of the soft key menu.
3 Press soft key [MOVE DIR].
4 Using the MDI keys, enter the number or name of the movement
destination directory. Alternatively, select this directory using the
cursor keys.
[Input format]
<directory-number>, <directory-name>, or <cursor>
5 Press soft key [EXEC].
6 During movement, MV blinks at the top of the screen.
NOTE
1 If a directory contains many files, it may take much
time to move to that directory.
2 A destination directory can be specified using a
directory number only if the directory is displayed on
the Hard Disk File Directory screen.
3 If the CNC software series is the F001 or F601, this
operation cannot be used.
