4.8.6 Outputting Custom Macro Variables
A file (custom macro variables) is output from the tape memory to the
data server board built-in hard disk or host computer built-in hard disk.
For the Macro Variable screen
Procedure
1 Place the CNC in EDIT mode.
2 Press function key
OFFSET
SETTING
.
3 Press the continuation menu key at the right end of the soft key
menu.
4 When soft key [MACRO] is pressed, the Macro Variable screen
appears.
5 Press soft key [(OPRT)].
6 Press the continuation menu key at the right end of the soft key
menu.
7 Press soft key [PUNCH].
8 Press soft key [EXEC].
9 During output, "OUTPUT" blinks in the lower-right part of the
screen.
File name
Fixed to MACRO.
File formats and restrictions
Refer to each CNC operator' manual.
Output destination
In storage mode : Data server board built-in hard disk
In FTP mode : Host computer built-in hard disk
In buffer mode : Data server board built-in hard disk
