i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04
- -282
6.11.1 Checking the Hard Disk
Check whether the hard disk contains a faulty sector.
Procedure
1 Place the CNC in MDI mode.
2 Press function key
SYSTEM
.
3 Press soft key [CHAPTER].
4 When you press [MIN DATA SERVER], the Data Server
(Maintenance) screen appears.
5 Press the operation menu key at the right end of the soft key
menu.
6 Press soft key [CHECK DISK].
7 Press soft key [EXEC]. The results are displayed in RESULT OF
CHKDSK
l Normal status : NORMAL
l Abnormal status : ABNORMAL
CAUTION
If an abnormal status arises, check the cause of the
error by referring to the error message displayed on
the Ethernet Error Message screen. Then, quickly
back up the files stored on the hard disk.
Subsequently, format the hard disk.
NOTE
An error occurs if other data server functions are
executed concurrently with hard disk check.
