Ethernet/Data Server Board Operators manual Page 204

Operators manual
4.16i/18i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04
- -190
4.9.2 Changing the Connected Host
Check the host computer on which the FTP server, or the
communication destination of the current data server board, is running.
Procedure
1 Press function key
PROG
.
2 Press the continuation menu key at the right end of the soft key
menu.
3 When you press soft key [CONECT], the Connection Host screen
appears.
4 Press the continuation menu key at the right end of the soft key
menu.
5 Press soft key [CONECT 1], [CONECT 2], and [CONECT 3].
[Reference]
The title of the host computer, or the communication destination of the
current data server board, is displayed in reverse video.
NOTE
Some versions of the CNC system software allow
only host 1 to be specified for connection.
