Ethernet/Data Server Board Operators manual Page 242

Operators manual
6.15i
i i
i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04
- -228
To delete two or more files
Procedure
1 Display the Hard Disk File Directory screen.
2 Press the operation menu key at the right end of the soft key menu.
3 Press soft key [DEL FILE].
4 Using the MDI keys, enter the name of the file to be deleted
(including wild cards).
[Input format]
<file-name (including wild cards)>
5 Press soft key [EXEC].
6 If "FILE DELETE?" is displayed at the lower-left corner of the
screen, press soft key [EXEC]. To cancel the deletion, press soft
key [CAN].
7 During deletion, DEL blinks at the top of the screen.
8 To stop the deletion, press soft key [STOP].
[Example]
Enter * for the file name to delete all the files displayed on the Hard
Disk File Directory screen from the data server board built-in hard disk.
NOTE
When two or more files are being deleted, and soft
key [STOP] is pressed, the files deleted until soft key
[STOP] is pressed cannot be restored.
