Ethernet/Data Server Board Operators manual Page 177

Operators manual
B-63354EN/04 IV. OPERATION 4.16i/18i DATA SERVER FUNCTIONS
- -163
For the program screen
Procedure
1 Place the CNC in EDIT mode.
2 Press function key
PROG
.
3 Press the continuation menu key at the right end of the soft key
menu.
4 When you press soft key [PRGRM], the Program screen is
displayed.
5 Press soft key [(OPRT)].
6 Press the continuation menu key at the right end of the soft key
menu.
7 Press soft key [READ].
8 Enter the O number of the NC program to be entered using the
MDI keys.
[Input format]
<O-number>
9 Press soft key [EXEC].
10 During input, "INPUT" blinks in the lower-right part of the
screen.
CAUTION
1 When bit 2 of parameter No.3201 is 1, if the NC
program having the same O number as the NC
program to be input exists in the tape memory, it is
overwritten.
2 When bit 0 of parameter No.3201 is 1, if an NC
program is input, all NC programs in the tape memory
are automatically cleared. Subsequently, the NC
program is input.
NOTE
1 NC program input cannot be executed
simultaneously with NC program output, DNC
operation, and DNC operation by a subprogram call
(M198).
2 The O number used for input to the tape memory is
valid only for file name Oxxxx (xxxx: numeral).
3 In the buffer mode, a specified O number is assumed
to represent a list of files resulting from NC program
division. Therefore, an NC program is input by
regarding the files in the file list as a virtually single
continuous file.
