SERIES 15-150 MODEL B Connection manual Page 121

Connection manual
B–62073E/04
5. POWER SUPPLY UNIT AND INPUT
UNIT CONNECTION
114
(e) Connector CP95, CP96
These terminals are for ON/OFF–controlled, single–phase
200/220 VAC output. They are used for power supply to external
units. The rating of each terminal must be set such that the total of
the ratings of CP92 to PC96 does not exceed 1.4 kVA.
The following units can be mounted in stand–alone cabinet B and
additional lockers. All necessary PCB connections in the control unit (of
the main and additional lockers) are completed at the factory.
Unit Lockers PCB Connector Function Remark
9″ monochrome CRT unit MAIN
MAIN
MAIN
PSU
MAIN
MAIN
CP5
JA1
JA2
DC24V
CRT
MDI
Note 1)
Connection unit MAIN
MAIN
PSU
PMC
CP6
JD1A
DC24E
IOLINK
Note 2)
Tape reader MAIN MAIN JD5B RS232–2
Punch panel MAIN MAIN JD5A RS232–1
APC battery (1 pc only) ADD MAIN JA4A APCBAT
Servo amp. ADD AXIS JV1 to 4 AMP1 to 4 Note 3)
PSU : Power supply unit
MAIN : Main CPU board
PMC : PMC board
AXIS : Axis CPU board
MAIN : Main Cabinet
ADD : Additional Cabinet
NOTE
1 Can be used for power input when the 9″ monochrome CRT
unit is installed outside the cabinet.
2 Can be used for power input when the connection unit is
installed outside the cabinet.
3 The connections to be made will change, depending on the
ordered specifications.
