SERIES 15-150 MODEL B Connection manual Page 367

Connection manual
B–62073E/04
C. 20-PIN INTERFACE CONNECTORS
AND CABLES
APPENDIX
371
The numbers assigned to the wires correspond to the number in the table at right.
7
5
1
6
4
2
3
8
10
9
Dot
mark
(1 pitch)
Dot mark
color
First
wire
–
–
–
–
–
––
––
––
––
––
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Second
wire
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Insula-
tor
color
Orange
Gray
White
Yellow
Pink
Orange
Gray
White
Yellow
Pink
Pair
No.
1
2
3
4
5
6
7
8
9
10
Drain wire
Twisted–pair wire
Binding tape
Shield braid
Sheath
Fig. C (c) Cable made by Hitachi Cable
(7)Composite 12–core cable
(a) Specifications
Item Unit Specifications
Product No. — A66L–0001–0286
Manufacturer — Oki Cable, Ltd.
Hitachi Electric Cable Co., Ltd.
Rating — 80°C, 30 V
Material
Conductor,
braid–shielded
wire, drain wire
— Strand wire of tinned annealed copper (JIS C 3152)
Insulator — Heat–resistant flame–retardant vinyl
Sheath — Oilproof, heat–resistant, flame–retardant vinyl
Number of wires (wire nos.) Cores 6 (1 to 6) 6 (three pairs) (7 to 9)
Conductor
Size mm
2
0.5 0.18
Structure Conductors/
mm
20/0.18 7/0.18
Outside diameter mm 0.94 0.54
Insulator
Standard thickness
(The minimum
thickness is at least
80% of the standard
thickness.)
mm 0.25 0.2
Outside diameter mm 1.50 0.94
