SERIES 15-150 MODEL B Connection manual Page 94

Connection manual
B–62073E/04
4. TOTAL CONNECTION
87
A
D
D
I
T
I
O
N
A
L
C
A
B
I
N
E
T
2ND AXIS SERVO AMP/MOTOR/PULSE CODER/SCALE
POWER SUPPLY
AC–IN(CP1)
1ST CPU BOARD
SPDL–1(JA7A)
ASPDL–1(JA8A)
APCBAT(JA4)
AMP1(JV1)
ENC1(JF1)
SCALE1(JF21)
AMP2(JV2)
ENC2(JF2)
SCALE2(JF22)
AMP3(JV3)
ENC3(JF3)
SCALE3(JF23)
AMP4(JV4)
ENC4(JF4)
SCALE4(JF24)
ADDS1(JF61)
ADDS2(JF62)
ADDS3(JF63)
ADDS4(JF64)
NZ/ZD(JA16)
APC BATTERY
6V
CN1
AC100V
AC200V
1ST SERVO
MOTOR
SERIAL PULSE
CODER
SCALE
T1
1ST SERBO
AMP
ANALOG
INTERFACE
SPINDLE
200VAC
SPINDLE
MOTOR
POSITION
CODER
EMERGENCY STOP
CPD1
CPD2C
INPUT T
UNIT
BUFFER BOARD
MAX BUS(JNC)
To control unit (Main CPU board “JNC”)
2ND CPU BOARD
3RD AXIS SERVO AMP/MOTOR/PULSE CODER/SCALE
4TH AXIS SERVO AMP/MOTOR/PULSE CODER/SCALE
1ST AXIS PULSE POSITION DETECTOR
2ND AXIS PULSE POSITION DETECTOR
3RD AXIS PULSE POSITION DETECTOR
4TH AXIS PULSE POSITION DETECTOR
Reference position approach signal
More than one axis CPU board may be used, depending
on the system configuration.
PCR 20 connector (20 pins)
PCR 20 connector (15 pins)
AMP connector
Others
NOTE
Some connections in the above diagram may not be
provided, depending on the system configuration.
