SERIES 15-150 MODEL B Connection manual Page 296

Connection manual
B–62073E/04
A. LIST OF EXTERNAL DIMENSIONSAPPENDIX
333
Fig. 17 (d) External view of HONDA connector (terminal layout)
Fig. 18 (a) External view of connector made by FCI Japan (3 pins, black)
Fig. 18 (b) External view of connector made by FCI Japan (3 pins, brown)
Fig. 18 (c) External view of connector made by FCI Japan (3 pins, white)
Fig. 18 (d) External view of connector made by FCI Japan (6 pins, brown)
Fig. 18 (e) External view of connector made by FCI Japan (6 pins, white)
Fig. 19 (a) External view of reader puncher panel connector
Fig. 19 (b) External view of reader puncher connector metal fitting for lock
Fig. 20 External view of power receptacle for portable tape reader
Fig. 21 External view of battery case for absolute pulse coder
Fig. 22 External View of the Extension Adaptor Unit for Series 15–B
(MMC–II)
Fig. 23 External View of the Keyboard for Series 15–B (MMC–II)
Fig. 24 External view of the hard disk unit for Series 15–B (MMC–II)
Fig. 25 External view of the Portable 5″ Floppy Disk Unit for Series 15–B
(MMC–II)
Fig. 26 External view of the Portable 3.5″ Floppy Disk Unit for Series 15–B
(MMC–II)
Fig. 27 External view of the Portable Cassette Streamer Unit for Series
15–B (MMC–II) (A08B–0047–C071)
