Power Failure Backup Module Descriptions Additional Manual Page 1

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
1
/
93
DESCRIPTIONDESIG.DATE
Power Failure Backup Module
Descriptions
A-53866E-464
Power Failure Backup Module Descriptions
1. Type of applied technical documents
Name FANUC SERVO AMPLIFIER αi series DESCRIPTIONS
Spec.No./Version A-53866E-464
2. Summary of change
Group Name / Outline New, Add,
Correct,
Delete
Applicable
Date
Basic
Function
Power Failure Backup Module New 2005.05
Optional
Function
Unit
Maintenance
parts
Notice
Correction
Another
In this descriptions, the contents of the following descriptions are
included.
• B-65162/03-04 Edition 01
• B-65162/03-08 Edition 03
• B-65162/03-10 Edition 01
• A-53866-401 Edition 01
• A-53866-405 Edition 01
01 05.05.09 S.Hanyu Newly added
In this manual we have tried as much as possible to describe all the various matters.
However, we cannot describe all the matters which must not be done, or which cannot be done,
because there are so many possibilities.
Therefore, matters that are not especially described as possible in this manual should be regarde
d
as “impossible”.
