Power Failure Backup Module
Descriptions
A-53866E-464
The sum of the maximum outputs of the motors to be decelerated simultaneously in the
event of a power failure is
32.2 kW (condition <1>).
The sum of the products of the maximum outputs and the deceleration times of the each
motor to be decelerated in the event of a power failure is 23.62 kWsec
(condition <2>).
Selection results
You can select either two A06B-6089-H712s in parallel
or one A06B-6077-H020.
* If you perform processing that decelerates the servo motor first and then the spindle
motor, the sum of the maximum outputs of the motor to be decelerated simultaneously
is less than 20 kW, so that you may select one A06B-6089-H712
.
N
OTE
The sum of the maximum outputs of the motors to be decelerated simultaneously in the event of
a
power failure may be up to 40 kW.
Only one sub module R A06B-6077-H020 or A06B-6091-H020 may be used. You canno
t
connect two or more of these models in parallel.
Up to two sub modules R A06B-6089-H712 may be connected in parallel.
