Power Failure Backup Module Descriptions Additional Manual Page 10

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
10
/
93
DESCRIPTIONDESIG.DATE
Power Failure Backup Module
Descriptions
A-53866E-464
2.2 ORDERING INFORMATION
2.2.1 Power Failure Backup Module
Category Name Ordering number Remarks
Standard Power failure
backup module
A06B-6077-H002 200V input type
Standard Power failure
backup module
A06B-6091-H002 400V input type
2.2.2 Sub module C
Category Name Ordering number Remarks
Standard Sub module C A06B-6077-H010 25000 µF/400V
Standard Sub module C A06B-6083-H245 9000 µF /800V
2.2.3 Sub module R
Category Name Ordering number Remarks
A06B-6089-H712 8Ω / 200V input type
A06B-6077-H020 4Ω / 200V input type
Standard Sub module R
(regenerative
discharge unit)
A06B-6091-H020 4Ω / 400V input type
2.2.4 Supplement capacitor unit
Category Name Ordering number Remarks
Standard Supplement
capacitor unit
A06B-6077-H010 Same ordering number as that of sub
module C (200V input type)
2.2.5 PSM for power failure backup module (Use a Standard PSM with an αi series amplifier)
Category Name Ordering number Remarks
Standard PSM-5.5 A06B-6077-H106#BM
PSM-11 A06B-6077-H111#BM
PSM-15 A06B-6087-H115#BM
PSM-26 A06B-6087-H126#BM
PSM-30 A06B-6087-H130#BM
PSM-37 A06B-6087-H137#BM
PSM-45 A06B-6087-H145#BM
PSM-55 A06B-6087-H155#BM
PSM-18HV A06B-6091-H118#BM
PSM-30HV A06B-6091-H130#BM
PSM-45HV A06B-6091-H145#BM
PSM-75HV A06B-6091-H175#BM
The method of selecting a PSM is the
same as that of selecting a
standard PSM (#BM-less).
Add #BM to the end of the number of
the PSM selected in accordance with
the Descriptions B-65162E.
The external dimension is the same
as that of standard PSMs.
