Power Failure Backup Module Descriptions Additional Manual Page 8

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
8
/
93
DESCRIPTIONDESIG.DATE
Power Failure Backup Module
Descriptions
A-53866E-464
N
OTE
3. If a power failure occurs during heavy cutting, the DC link low voltage alarm may be generate
d
b
efore the brake starts to operate, so that a gravity axis drop cannot be prevented. To prevent
a
gravity axis drop even in such a case, you must connect sub module C.
4. If a power failure occurs during spindle acceleration or all-axis simultaneous acceleration, the DC
link low voltage alarm may be generated, so that the stop distance cannot be reduced sufficiently.
To increase the effect of stop distance reduction even in such a case, you must connect sub module
C.
5. If the power failure backup module used is of the 400V input type (A06B-6091-H002), the
supplement capacitor unit is not required.
