Power Failure Backup Module
Descriptions
A-53866E-464
2.2.6 Connectors
Category Name Ordering number Remarks
Standard Connector A06B-6077-K212 Crimped type
A06B-6077-K213 Soldered type
A06B-6091-K212 Crimped type
A06B-6091-K213 Soldered type
2.2.7 Fuses
Category Name Ordering number Remarks
Standard Fuse A06B-6077-K255 FU1,FU2(10A), FU3(3.2A)
2.2.8 Circuit Breaker
Category Name Ordering number Rated current Remarks
Option Breaker 1 Refer to the Descriptions B-65162E or B-65282EN.
Breaker 2 A06B-6077-K106 5A Fuji Electric EA33/5
Breaker 3 - 3A Fuji Electric EA33/3
Breaker 4 - 3A Fuji Electric EA33/3
2.2.9 Cables
(1) DC link short bar
Refer to the Descriptions B-65282EN or B-65162E.
(2) Cable for connecting between a power failure backup module and an amplifier
Category Name Ordering number Cable
length
Remarks
A06B-6082-K808 200mm
A06B-6082-K809 150mm
Optional Cable for
connection
modules
A06B-6082-K810 100mm
Contains the following cables:
K59: For +24V control power supply
K63: For interface between modules
