Power Failure Backup Module Descriptions Additional Manual Page 88

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
88
/
93
DESCRIPTIONDESIG.DATE
Power Failure Backup Module
Descriptions
A-53866E-464
9. RESTRICTIONS ON CONNECTING αi SERIES AMPLIFIERS
If connecting the power failure backup module to αi series amplifiers, you must provide external control
power supply for some of the amplifiers depending on the number of amplifiers to be connected.
9.1 CONDITIONS UNDER WHICH AN EXTERNAL CONTROL POWER SUPPLY MUST BE PROVIDED
If sum N of the constants n for the PSM and the SPMs and SVMs connected to the PSM (Table 1) exceeds 7
(N > 7), it is necessary to provide an external control power supply.
(If N
≤ 7, you need not provide an external power supply.)
Provide an external power supply for any SPM or SVM, so that the sum N (Table 1) of the constants n for the
SPMs and SVMs that the PSM supplies control power is 7 or less.
Table 1. Constants n for SPMs/SVMs
Amplifier model n
PSM-5.5i to 37i, 11HVi to 45HVi (60mm wide/90mm wide/150mm wide type)
1
PSM
PSM-55
i, 75HVi, 100HVi (300mm wide type)
1.5
SPM-2.2i to 30i, 5.5HVi to 45HVi (60mm wide/90mm wide/150mm wide type)
1.5
SPM
SPM-45
i, 55i, 75HVi, 100HVi (300mm wide type)
2.5
SVM1-20i to 80i (excluding 80Li), 10HVi to 40HVi (excluding 40HVLi)
1
SVM1-80Li, 160i, 160Li, 40HVLi, 80HVi, 80HVLi
1.5
SVM1-360i, 180HVi (150mm wide type)
2
SVM1
SVM1-360HV
i (300mm wide type)
2.5
SVM2 All models 1.5
SVM3 All models 2
[Examples]
Amplifier model
Number
of units
Corresponding n
value
n x
Number of
units
n x Number of
units
n x Number of
units
PSM-55i
1 1.5 1.5 1.5 1.5
SPM-26i
2 1.5 3 0 3
SVM1-80i
1 1 1 1 1
SVM2-80/160i
1 1.5 1.5 1.5 1.5
SVM2-160/160i
2 1.5 3 3 0
Total N 10 7 7
N > 7, thus, external power supply required
Example 1: Provide an external power supply for two SPM-26i's.
Example 2: Provide an external power supply for two SVM2-160/160i's.
