Power Failure Backup Module
Descriptions
A-53866E-464
7. SIGNAL HANDLING AND PARAMETER SETTING
The machine protection functions at power failure control the necessary machine protection operations in
the CNC, in response to the power failure detection signal output from the power failure backup module as
soon as a power failure occurs. This chapter provides an overview of the handling of signals for the
machine protection operations, as well as parameter setting.
For details of parameter setting, refer to the connection manual (functions) and the parameter manual of
the CNC used.
7.1 RETRACT FUNCTION AT POWER FAILURE
The Retract function at power failure performs retract operation by manipulating the retract signal of the
CNC, in response to the power failure detection signal (*PFL) output from the power failure backup
module. After a power failure occurs, the processing in the PMC must be at the first level (8 msec
interval) to minimize the energy loss until the start of retract operation.
