Power Failure Backup Module Descriptions Additional Manual Page 62

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
62
/
93
DESCRIPTIONDESIG.DATE
Power Failure Backup Module
Descriptions
A-53866E-464
6.2.2 MCC Shutoff Sequence
The sequence is common to the A06B-6077-H002 (200V type) and the A06B-6091-H002 (400V type).
MCC ON OFF
*CRDY (PSM internal ready signal)
RDY (CX16 B3)
LED indication "0" indication "-" indication
When the MCC is shut off, RDY becomes 0. At the same time, the LED indication changes from
"0" to "-".
6.2.2 Sequence in the Event of a Power Failure
(Control of the Supply of the DC Link Voltage to the Control Power Supply)
(1) For the A06B-6077-H002 (200V type)
Input voltage (200 VAC)
Power failure detection signal
*PFL (CX16 B2)
CX13 output DC link voltage output
Power failure backup module 24 VDC input (CX14) DC24V DC20V
(PSM 24 VDC output (αPSM:CX2B, α
i
PSM:CXA2A))
30msec MAX
Power failure
Power failure detected
200 VAC output
DC output at CX13 shut
off when the CX14
input is approx. 20 V
