Power Failure Backup Module Descriptions Additional Manual Page 9

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
9
/
93
DESCRIPTIONDESIG.DATE
Power Failure Backup Module
Descriptions
A-53866E-464
2.1.4 Notes
(1) In case that a dynamic brake module (DBM) is connected
If connecting the power failure backup module to a servo amplifier module with a dynamic brake
module (DBM) connected, you need an uninterruptible power supply (UPS) with an output of
200VDC for driving the DBM(*). See (18) in Section 5.2 for details.
* Power for driving the operating coil for the built-in contactor of the DBM
(2) Retraction along the vertical axis
For retraction along the vertical axis in the event of a power failure, you must
maintain the power for the brake so that the brake does not operate due to a power
failure.
For an αi /αHVi motor
Back up the brake power of 24 VDC.
The switching power supply for the brake (24 VDC output) can be backed up
from the power failure backup module. For information on the specifications
required of the switching power supply, see (5) in Chapter 3.
For an α/αHV motor
Back up the brake power of 90 VDC.
If you can obtain a switching power supply with an output of 90 VDC, which
meets (5) in Chapter 3, you can back up the switching power supply from the
power failure backup module. In general, however, a switching power supply
with an output of 90 V is hard to obtain and if you cannot obtain one, back
it up with an uninterruptible power supply (UPS), etc.
