B-75074EN/04 INSTALLATION 5.BACKUP AND RESTORATION

- 103 -

5.1 BACKUP

If you changed the settings of i CELL or customized any i CELL

dialog box, be sure to back up i CELL, using the following procedure.

When i CELL is backed up, its multiple files and directories are

assembled and compacted into a single backup archive file. i CELL

can be restored from this file according to the procedure described in

Section 5.2, "RESTORATION".

NOTE

Before starting backing up i CELL, be sure to

terminate the i CELL project.

5.1.1 Opening the IcellBkupRstr Dialog Box

Click the [Start] button, select [Programs] - [CIMPLICITY i CELL],

and activate the [Backup & Restore] icon.
