5.3 CIMPLICITY SCRIPT SETTING

Initiation and termination of CNC Connection must be linked to the

initiation and termination of the target program. Linking requires that

appropriate settings be made in the two scripts of CIMPLICITY, em_init.bcl

and em_term.bcl.

Making various settings in the [Script] dialog box in the Configuration

dialog box causes the settings to be reflected in em_init.bcl and em_term.bcl.

This section describes how to make settings in the [Script] dialog box. It

also describes how to set various options of CNC Connection.

5.3.1 Initiation and Termination Scripts

em_init.bcl

This script is automatically executed when the project is initiated. The

initiation process for CNC Connection is inserted there. The setting file

and various options for use with CNC Connection are also set there.

Clicking the <OK> button in the [Script] dialog box causes the settings to be

inserted into em_init.bcl as a script. The settings that have been written

before the insertion remain unchanged. For information on customizing

em_init.bcl, see Subsection 5.3.3, "Settings in the Initialization/Termination

Scripts".

When CNC Connection is started, the icon shown below appears in the task

bar.

NOTE

1 When i CELL is used, there is no need to make settings in

particular because the settings in CIMPLICITY scripts have

already been made. Except if the settings of point setting

completion notification points have been changed and except for

special cases, it is recommended that the settings be left

unchanged.

2 If CNC Communication Mode is used for the first time, the

initiation and termination of CNC Connection are not linked to

the initiation and termination of the target project because

settings have not been made in CIMPLICITY scripts. Be sure

to make settings in CIMPLICITY scripts.
