2. FUNCTION EXPLANATION
B–65160E/02
104
(1) In case of Series 0
Diagnosis number Contents
Machining
(M series)
Turning
(T series)
Mchining Turning
unit
0800 0800 Position error of X axis Position error of X axis pulse
0801 0801 Position error of Y axis Position error of Z axis pulse
0802 Position error of Z axis pulse
The contents below is shown in the paramter display.
The parameter address below is used for monitoring.
Parameter number
Machining
(M series)
Turning
(T series)
Contents unit
0627 0435 Position error pulse of the spindle pulse
0628 0436 Interpolation pulse of the spindle pulse
0696 0437
Instant value of the position error difference
between the tapping axis and the spindle
%
0697 0438
Maximum value of the position error difference
between the tapping axis and the spindle
%
0799 Integrated interpolation pulse of the spindle pulse
(2) Series 15
Address Contents unit
Position error pulse of the tapping axis pulse
3000
Position error pulse of the spindle pulse
(3) Series 16i/16
Address Contents unit
0300 Position error pulse of the tapping axis pulse
0450 Position error pulse of the spindle pulse
0451 Interpolation pulse of the spindle pulse
0454 Integrated interpolation pulse of the spindle pulse
0455
Difference of move command converted for the spindle
(instantaneous)
pulse
0456
Difference of positional deviation converted for the spindle
(instantaneous)
pulse
0457 Width of synchronization error pulse
2.4.6
Diagnosis
