AC Spindle Motor Alpha Series Parameter manual Page 369

Parameter manual
APPENDIX
B. LIST OF SPINDLE PARAMETER
NUMBERS
B–65160E/02
360
Spindle switching
MAIN side
Contents
Spindle switching
SUB side
High
–speed
charac-
teristics
Contents
Low
–speed
charac-
teristics
High
–speed
charac-
teristics
Low
–speed
charac-
teristics
3247 3251 3252 3253 Time constant for spindle load monitor
magnetic flux compensation
3248 3281 3282 3283 Spindle load monitor torque constant
3249 ² 3234 ² Spindle load monitor observer gain 1
3250 ² 3235 ² Spindle load monitor observer gain 2
3312 ² 3316 ² Detection level 2 for completion signal for
orientation by position coder
3313 ² 3317 ² Detection level 1 for completion signal for
orientation by magnetic sensor
3314 ² 3318 ² Detection level 2 for completion signal for
orientation by magnetic sensor
3315 ² 3319 ² Stop position shift in orientation by mag-
netic sensor
3320 ² 3324 ² Motor deceleration time constant (HIGH)
3321 ² Motor deceleration time constant
(MEDIUM HIGH)
3322 ² Motor deceleration time constant
(MEDIUM LOW)
3323 ² 3325 ² Motor deceleration time constant (LOW)
3326 ² 3327 ² Speed at which deceleration time
constant limit starts (HIGH)
3330 ² 3331 ² Speed at which deceleration time
constant limit starts (LOW)
3328 ² 3329 ² Command multiplication for spindle
orientation by position coder
3334 ² 3335 ² Arbitrary number of velocity detector
pulses
3336 ² Magnetic flux switching point for calculat-
ing acceleration/deceleration time
constant during spindle synchronization
3337 ² 3338 ² Velocity loop gain speed compensation
factor
3339 ² ² ² Torque clamp level
3340 ² Bell–shaped acceleration/deceleration
time constant during spindle synchroniza-
tion
3341 ² ² ² Abnormal torque detection level
3344 ² ² ² Advanced feed–forward factor
3345 ² ² ² Spindle motor velocity command detec-
tion level
3346 ² ² ² Incomplete integration factor
3347 ² Level for detecting speed difference be-
tween spindles 1 and 2 during slave op-
eration
3351 ² ² ² Current detection offset compensation
