FANUC AC SPINDLE MOTOR a series

3. EXPLANATION OF

PARAMETERS

B–65160E/02

216

16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15

NRROEN PC1CAT RFCHK4

6157 3337 3193 4193

6337 3557

Standard setting: 0 0 0 0 0 0 0 0

RFCHK4:

Specifies whether to use the position coder 1-rotation signal detection

function in normal rotation

0: Does not detect the 1-rotation signal in normal rotation.

1: Detects the 1-rotation signal in normal rotation.

PC1CAT:

Specifies whether a position coder one–rotation signal is detected

during spindle orientation by a magnetic sensor.

0: Not detected.

1: Detected.

NRROEN:

Specifies whether the shortcut function is used when spindle

orientation by a position coder is performed from the stopped state.

0: Not used.

1: Used.

When this bit is set to 1, the shortcut function is used when the

following requirements are satisfied:

D Bit 7 (RFCHK3) of parameter No. 4192 is set to 0.

D The speed zero signal SST is set to 1.

D The shortcut command NRRO is set to 1.

16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15

PRLOAD VDCV1 SDTCHG SSTTRQ

6159 3339 3195 4195

6339 3559

Standard setting: 0 0 0 0 0 0 0 0

SSTTRQ:

Specifies whether to use torque clamping at speed of 0

0: Uses clamping.

1: Does not use clamping.

SDTCHG:

Specifies whether to switch from the high–speed range to low–speed

range upon the speed detection signal (SDT) being set to 1 when

output switching is used.

0: Switches regardless of the speed detection signal (SDT).

1: Switches when the speed detection signal (SDT) is set to 1.

VDCV1: Specifies whether DC link voltage detection filter processing is

performed.

0: Performed. (Normally set to 0)

1: Not performed.
