2. FUNCTION EXPLANATION
FANUC AC SPINDLE MOTOR a series
83
(1) Set the parameter “Position coder signal is used”
The parameter setting address is as follows.
0
T/M/TT
Fst. sp
0
T/TT
Snd. sp
15
T/M
15i 16i/16
T/M/TT
Setting
data
6501 #2 6641 #2 3001 #2 3001 #2 4001 #2 1
0: Position coder signal is not used
1: Position coder signal is used
(2) Set the parameter “Rotation direction of the motor and the spindle”
The parameter setting address is as follows.
0
T/M/TT
Fst. sp
0
T/TT
Snd. sp
15
T/M
15i 16i/16
T/M/TT
6500 #0 6640 #0 3000 #0 3000 #0 4000 #0
0: Spindl and motor are the same direction
1: Spindl and motor are the reverse direction
The rotation direction is judged from the same direction facing to the
motor Normally to the shaft of motor and the spindle.
SetHThe same directionIin case of the built– in motor.
(3) Set the parameter “Attached direction of the position coder”
The parameter setting address is as follows.
FS0
T/M/TT
Fst. sp
FS0
T/TT
Snd. sp
FS15
T/M
15i 16i/16
T/M/TT
6500 #2 6640 #2 3000 #2 3000 #2 4000 #2
0: The spindle and the position coder is the same direction
1: The spindle and the position coder is the reverse direction
The rotation direction of the position coder is judged facing to the
position coder shaft.
The rotation direction of the spindle is judged from the same direction
facing to the motor (Normally to the shaft).
(4) Set the parameter “Number of pulse of the position coder”
0 15 15i 16i/16 Setting data
– – 5842 – 4096
(5) Parameter setting relating to the system in which the position
coderis used.
When the gear ratio between the spindle and the position coder is 1:
2, 1: 4, and 1: 8.
Refer to each CNC operation manual about the relation between the
gear ratio and the parameter setting data.
0
M
Fst. sp
0
T/TT
Fst. sp
0
T/TT
Snd. sp
15
T/M
15i 16i/16
T/M/TT
Fst. sp
16i/16
T/TT
Snd. sp
0028
#7, 6
0003
#7, 6
0064
#7, 6
5610 – 3706
#1, 0
3707
#1, 0
2.4.4
Detail of Parameter for
Rigid Tapping
