AC Spindle Motor Alpha Series Parameter manual Page 281

Parameter manual

Page of 424

/ 424

FANUC AC SPINDLE MOTOR aC series

2. EXPLANATION OF

FUNCTIONS

B–65160E/02

272

G. Check spindle switching operation.

D Position gain on rigid tapping

D Acc/Dec time constant on rigid tapping

D others

A.Check that normal operation can be performed.

B.Prepare and check the ladder program for Rigid tapping.

B.(See Sec. 11.2 in the Descriptions (B–65162E).)

C.Set the parameters related to Rigid tapping

D The motor speed data calculated from the position coder signal is used

D The relationship of the rotation direction between spindle and spindle motor

D Mounting direction of the position coder

D Gear ratio

D Position gain on rigid tapping

D Acc/Dec time constant on rigid tapping

D Maximum spindle speed on rigid tapping

D.Check the velocity error of the spindle motor during the rigid tapping

D Velocity loop proportional, integral gain on servo mode(rigid tapping)

D Motor voltage setting on servo mode(rigid tapping)

D Position gain on rigid tapping

E.Check the torque command.

D Acc/Dec time constant on rigid tapping

F.Check the position error of the spindle motor during the rigid tapping

D Position gain on rigid tapping

D Gear ratio

Parameters are underscored. See Section 2.3.2.

2.3

Rigid Tapping

(9D12 Series Only)

2.3.1

Start–up Procedure
