1. Fanuc
  2. AC Spindle Motor Alpha Series

AC Spindle Motor Alpha Series Parameter manual Page 363

Parameter manual
APPENDIX
B. LIST OF SPINDLE PARAMETER
NUMBERS
B–65160E/02
354
Spindle switching
MAIN side
Spindle switching
SUB side
High
–speed
charac-
teristics
Low
–speed
charac-
teristics
High
–speed
charac-
teristics
Low
–speed
charac-
teristics
Contents
3000 ² 3176 ² Bit parameter
3001 ² 3177 ² Bit parameter
3002 ² 3178 ² Bit parameter
3003 ² 3179 ² Bit parameter
3004 ² 3180 ² Bit parameter
3005 ² 3181 ² Bit parameter
3006 ² 3182 ² Bit parameter
3007 ² 3183 ² Bit parameter
3008 ² 3184 ² Bit parameter
3009 ² 3185 ² Bit parameter
3010 ² 3186 ² Bit parameter
3011 ² 3187 ² Bit parameter
3012 ² 3188 ² Bit parameter
3013 ² 3189 ² Bit parameter
3014 ² ² ² Bit parameter
3015 ² ² ² Bit parameter
3016 ² 3192 ² Bit parameter
3017 ² 3193 ² Bit parameter
3018 ² 3194 ² Bit parameter
3019 ² 3195 ² Bit parameter
3020 ² 3196 ² Maximum motor speed
3021 ² Maximum speed in Cs contour control
mode
3022 ² 3197 ² Speed arrival detection level
3023 ² 3198 ² Speed detection level
3024 ² 3199 ² Speed zero detection level
3025 ² 3200 ² Limited torque
3026 ² 3201 ² Load detection level 1
3027 ² ² ² Load detection level 2
3028 ² 3202 ² Limited output pattern
3029 ² 3203 ² Output limit
3030 ² ² ² Soft start/stop time
3031 ² 3204 ² Stop position in orientation by position
coder
3032 ² ² Acceleration/deceleration time constant
during spindle synchronization
B.3
FOR FANUC
Series 15i
Previous page
Next page
