AC Spindle Motor Alpha Series Parameter manual Page 29

Parameter manual
FANUC AC SPINDLE MOTOR a series
1. ADJUSTMENT
B–65160E/02
20
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
CSDET3 CSDET2 CSDET1
6502 3002 3002 4002
6642 3142
1st–
2nd–
CSDET3-1:
Cs contouring control resolution setting.
(The bits of this parameter are invalid when a sensor Cs contour
control function is used.)
CSDET3 CSDET2 CSDET1
Cs contouring control
resolution
0 0 0 360000p/rev.
0 0 1 180000p/rev.
0 1 0 120000p/rev.
0 1 1 90000p/rev.
1 0 0 60000p/rev.
1 0 1 40000p/rev.
1 1 0 20000p/rev.
1 1 1 10000p/rev.
(To be set to 000 usually)
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
PCPL2 PCPL1 PCPL0 PCTYPE PCCNCT PCMGSL
6503 3003 3003 4003
6643 3143
1st–
2nd–
PCMGSL:
Selection of position coder method/magnetic sensor method spindle
orientation
0: Position coder method spindle orientation function
1: Magnetic sensor method spindle orientation function
Set this bit to 1 to use the magnetic sensor method spindle orientation.
Before this function can be used, the CNC software option of the spindle
orientation function must be selected.
PCCNCT:
Specifies whether a MZ sensor or BZ sensor (built–in motor) in a
motor is used.
0: Not used.
1: Used.
Set this bit to 1 when a MZ sensor is used. Set this bit to 1 when a built–in
motor with a BZ sensor is used.
