AC Spindle Motor Alpha Series Parameter manual Page 116

Parameter manual
B–65160E/02
2. FUNCTION EXPLANATION
FANUC AC SPINDLE MOTOR a series
107
(1) Input signal (PMC to CNC)
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
CON COFF
(M) (T)
G123
CON
(T/M)
G027
G67, 71..G67, 71..
MRDYA ORCMA SFRA SRVA CTH1A CTH2A TLMHA TLMLA
G229 G227 G070
RCHA RSLA INTGA SOCNA MCFNA SPSLA *ESPA ARSTA
G230 G226 G071
(2) Output signal (CNC to PMC)
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
FSCSL
F178 F044
F67, 71..F67, 71..
ORARA TLMA LDT2A LDT1A SARA SDTA SSTA ALMA
F281 F229 F045
RCFNA RCHPA CFINA CHPA
F282 F228 F046
Parameter No.
0T 0M 15 15i 16i/16
Description
3rd axis 4th axis 1804 1804 #7 1023 Specifies the axes subject to Cs contouring control.
0037 #7 1804 #0 – –
Specify ”High–resolution pulse coder is not used.” for this
parameter.
0037 #3, 2 1815 #1 – 1815 #1 Specify ”Separate pulse coder is not used.” for this parameter.
0021 #3, 2 1815 #5 – 1815 #5
Specify ”Other than absolute–position detector” for this
parameter.
–
5609
#1, 0
5609
#0
–
Specifies whether to automatically set a position gain for those
axes that are not under Cs contouring control.
6569
to
6572
3069
to
3072
3069
to
3072
4069
to
4072
Position gain for axes subject to Cs contouring control
(A parameter is selected by the CTH1A and CTH2A input
signals sent from the PMC.)
6780
to
6799
5609
#0
#1
5609
#0
3900
to
3944
Position gain for those axes that are not controlled under Cs
contouring control
(A parameter is selected by the CTH1A and CTH2A input
signals sent from the PMC.)
0102 0103 1820 1820 1820 Specify 2 (= 1 time) for command multiplication.
0065 #1 1005 #0 – 3700 #1
Specifies whether to enable the reference position return
function for the first G00 command received after switching to
Cs contouring control.
0502 0503 1827 5879 1826 Effective area
0506 0507 1828 5880 1828 Position error limit during movement
2.5.3
Parameters
Previous page
Next page
