AC Spindle Motor Alpha Series Parameter manual Page 82

Parameter manual
B–65160E/02
2. FUNCTION EXPLANATION
FANUC AC SPINDLE MOTOR a series
73
16i/160
15 15i
Gear ratio (HIGH) CTH1A=0, CTH2A=0
6556 3056 3056 4056
6696 3196
1st–
2nd–
Gear ratio (MEDIUM HIGH) CTH1A=0, CTH2A=1
6557 3057 3057 4057
6697 3197
1st–
2nd–
Gear ratio (MEDIUM LOW) CTH1A=1, CTH2A=0
6558 3058 3058 4058
6698 3198
1st–
2nd–
Gear ratio (LOW) CTH1A=1, CTH2A=1
6559 3059 3059 4059
6699 3199
1st–
2nd–
Data unit : Motor rotation for one rotation of spindle 100
(When parameter No. 4006 #1 (GRUNIT) is 1,
motor rotation 1000)
Data range : 0 to 32767
Standard setting : 100
These parameters set the gear ratio of the spindle motor relative to the
spindle.
When the motor rotates 2.5 time for every rotation of the spindle, for
example, set 250 in the parameter.
A parameter is selected by the CTH1A and CTH2A input signals.
The gear or clutch status must correspond to the status of the CTH1A and
CTH2A input signals.
16i/160
15 15i
Position gain on orientation (HIGH) CTH1A=0, CTH2A=0
6560 3060 3060 4060
6700 3200
1st–
2nd–
Position gain on orientation (MEDIUM HIGH) CTH1A=0, CTH2A=1
6561 3061 3061 4061
6701 3201
1st–
2nd–
Position gain on orientation (MEDIUM LOW) CTH1A=1, CTH2A=0
6562 3062 3062 4062
6702 3202
1st–
2nd–
Position gain on orientation (LOW) CTH1A=1, CTH2A=1
6563 3063 3063 4063
6703 3203
1st–
2nd–
Data unit : 0.01 sec
–1
Data range : 0 to 32767
Standard setting : 1000
These data are used to set the position gain on orientation.
Parameter is set depend on input signal CTH1A or CTH2A.
16i/160
15 15i
Modification rate of position gain on orientation completion
6564 3064 3064 4064
6704 3204
1st–
2nd–
Data unit : 1%
Data range : 0 to 1000
Standard setting : 100
This data is used to set the modification rate of position gain on
spindle orientation completion.
16i/160
15 15i
