AC Spindle Motor Alpha Series Parameter manual Page 385

Parameter manual
APPENDIX
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
B–65160E/02
376
Motor model name αP8 αP8/8000 αP12 αP12/8000
Applicable amplifier SPM–11 SPM–11 SPM–11 SPM–11
Model code (applicable software) 112 (9D00/G) – 112 (9D00/G) –
Output specifications
Parameter No.
3.7/5.5 kW
750/6000
min
–1
3.7/5.5 kW
750/8000
min
–1
5.5/7.5 kW
750/6000
min
–1
5.5/7.5 kW
750/8000
min
–1
FS0 FS15 FS15i FS16i/16
6507 3007 3007 4007 10000000 ² 10000000 ²
6508 3008 3008 4008 00000001 ² 00000000 ²
6509 3009 3009 4009 00100000 ² 00000000 ²
6511 3011 3011 4011 00111010 ² 00111010 ²
6512 3012 3012 4012 00000000 ² 00000000 ²
6513 3013 3013 4013 00011010 ² 00011010 ²
6519 3019 3019 4019 00001100 ² 00001100 ²
6520 3020 3020 4020 6000 8000* 6000 8000*
6539 3039 3039 4039 0 ² 0 ²
6580 3080 3080 4080 50 40* 50 ²
6600 3100 3100 4100 750 ² 610 ²
6601 3101 3101 4101 90 ² 100 ²
6602 3102 3002 4002 1040 ² 1000 ²
6603 3103 3003 4003 1040 ² 1000 ²
6604 3104 3004 4004 2000 ² 2000 ²
6605 3105 3005 4005 2000 ² 2000 ²
6606 3106 3006 4006 2000 ² 1500 ²
6607 3107 3007 4007 2000 ² 1500 ²
6608 3108 3008 4008 300 ² 300 ²
6609 3109 3009 4009 10 ² 10 ²
6610 3110 3110 4110 774 ² 794 ²
6611 3111 3111 4111 23 ² 27 ²
6612 3112 3112 4112 500 ² 500 ²
6613 3113 3113 4113 420 ² 140 ²
6614 3114 3114 4114 0 ² 8 ²
6615 3115 3115 4115 5 ² 5 ²
6616 3116 3116 4116 100 ² 107 ²
6617 3117 3117 4117 20 ² 20 ²
6618 3118 3118 4118 30 ² 30 ²
6619 3119 3119 4119 0 ² 0 ²
6620 3120 3120 4120 38 ² 40 ²
6624 3124 3124 4124 0 ² 0 ²
6627 3127 3127 4127 178 ² 164 ²
6628 3128 3128 4128 10000 ² 6000 ²
6629 3129 3129 4129 0 ² 0 ²
6630 3130 3130 4130 0 ² 0 ²
6933 3313 3169 4169 0 ² 0 ²
C.2
SPINDLE MOTOR α P
Series
