AC Spindle Motor Alpha Series Parameter manual Page 395

Parameter manual
APPENDIX
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
B–65160E/02
386
Motor model name α22HVα18HVα15/HVα12HVα8HVα6HV
Applicable amplifier SPM–26HVSPM–26HVSPM–26HVSPM–15HVSPM–11HVSPM–11HV
Model code (applicable software) 132 (9D0A/A)131 (9D0A/A)130 (9D0A/A)–––
Output specifications
Parameter No.
22/26 kW
1500 /6000
min
–1
18.5/22 kW
1500 /6000
min
–1
15/18.5 kW
1500/6000
min
–1
11/15 kW
1500/6000
min
–1
7.5/11 kW
1500/6000
min
–1
5.5/7.5 kW
1500/8000
min
–1
FS0 FS15 FS15i FS16i/16
6630 3130 3130 4130 0 0 0 0 0 0
6933 3313 3169 4169 0 0 0 0 0 0
Motor model name α30HV α40HV α60HV
Applicable amplifier SPM–45HV SPM–45HV SPM–75HV
Model code (applicable software) 133 (9D0A/A) 134 (9D0A/A) 133 (9D0A/A)
Output specifications
Parameter No.
30/37 kW
1150/4500
min
–1
37/45 kW
1500/6000
min
–1
60/75 kW
1150/4500
min
–1
FS0 FS15 FS15i FS16i/16
6507 3007 3007 4007 10000000 10000000 10000000
6508 3008 3008 4008 00000000 00000001 00000001
6509 3009 3009 4009 00000000 00000000 00000000
6511 3011 3011 4011 00001010 00001010 00001010
6512 3012 3012 4012 00000000 00000000 00000000
6513 3013 3013 4013 00101010 00101010 00101010
6519 3019 3019 4019 00001100 00001100 00001100
6520 3020 3020 4020 4500 6000 4500
6539 3039 3039 4039 0 0 0
6580 3080 3080 4080 60 60 75
6600 3100 3100 4100 1150 1500 1150
6601 3101 3101 4101 100 100 100
6602 3102 3102 4102 1150 1500 1150
6603 3103 3103 4103 1000 1350 1000
6604 3104 3104 4104 1500 1200 1200
6605 3105 3105 4105 1500 1200 1200
6606 3106 3106 4106 1500 1500 1500
6607 3107 3107 4107 1500 1500 1500
6608 3108 3108 4108 300 300 300
6609 3109 3109 4109 10 10 10
6610 3110 3110 4110 1078 718 1183
6611 3111 3111 4111 29 27 36
6612 3112 3112 4112 500 500 1000
6613 3113 3113 4113 105 95 85
6614 3114 3114 4114 14 0 13
6615 3115 3115 4115 3 3 3
6616 3116 3116 4116 100 105 115
6617 3117 3117 4117 20 20 20
6618 3118 3118 4118 30 20 30
6619 3119 3119 4119 0 0 0
6620 3120 3120 4120 50 50 50
