AC Spindle Motor Alpha Series Parameter manual Page 362

Parameter manual

Page of 424

/ 424

B–65160E/02

B. LIST OF SPINDLE PARAMETER

NUMBERS

APPENDIX

353

1st spindle

Contents

2nd spindle

Spindle switching

MAIN side

Contents

Spindle switching

SUB side

Spindle switching

MAIN side

Spindle switching

SUB side

High

–speed

charac-

teristics

Contents

Low

–speed

charac-

teristics

High

–speed

charac-

teristics

Low

–speed

charac-

teristics

High

–speed

charac-

teristics

Low

–speed

charac-

teristics

High

–speed

charac-

teristics

Low

–speed

charac-

teristics

3484 ² 3704 ² Bell–shaped acceleration/deceleration

time constant during spindle synchroniza-

tion

3485 ² ² ² 3705 ² ² ² Abnormal torque detection level

3488 ² ² ² 3708 ² ² ² Advanced feed–forward factor

3489 ² ² ² 3709 ² ² ² Spindle motor velocity command detec-

tion level

3490 ² ² ² 3710 ² ² ² Incomplete integration factor

3491 ² 3711 ² Level for detecting speed difference be-

tween spindles 1 and 2 during slave op-

eration

3495 ² ² ² 3715 ² ² ² Current detection offset compensation

3719 ² 3761 ² MZ sensor signal amplitude ratio com-

pensation (when using the a sensor Cs

contour control function)

3720 ² 3762 ² MZ sensor signal phase difference com-

pensation (when using the a sensor Cs

contour control function)

3721 ² 3763 ² BZ sensor signal amplitude ratio com-

pensation (when using the a sensor Cs

contour control function)

3722 ² 3764 ² BZ sensor signal phase difference com-

pensation (when using the a sensor Cs

contour control function)

Contents Summary of AC Spindle Motor Alpha Series Parameter manual

Page 1FANUC AC SPINDLE MOTOR α series PARAMETER MANUAL B–65160E/02  FANUC LTD, 1994
Page 2– No part of this manual may be reproduced in any form. – All specifications and designs are subject to change without notice. In this manual we have tried as much as possible to describe all the various matters. However, we cannot describe all the matters which must not be done, or which cannot be
Page 3B–65160E/02 DEFINITION OF WARNING, CAUTION, AND NOTE DEFINITION OF WARNING, CAUTION, AND NOTE This manual includes safety precautions for protecting the user and preventing damage to the machine. Precautions are classified into Warning and Caution according to their bearing on safety. Also, suppleme
Page 4B–65160E/02 PREFACE PREFACE This manual describes the spindle parameters for the FANUC servo amplifier a series. Chapter 1 describes the parameters used to start normal operation. Chapter 2 describes the parameters for each function. Chapter 3 describes each spindle parameter in detail. The paramete
Page 5PREFACE B–65160E/02 Related manuals The following six kinds of manuals are available for FANUC SERVO MOTOR α series. In the table, this manual is marked with an asterisk (*). Document Document name Major contents Major usage number D Specification FANUC AC SERVO MOTOR α series D Characteristics B–65
Page 6B–65160E/02 Table of Contents PREFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p–1 I. FANAC AC SPINDLE MOTOR α series 1. ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 7Table of Contents B–65160E/02 2.5.4 Detail of Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109 2.5.5 Additional Information on Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 8B–65160E/02 Table of Contents 1.3.1 The Motor Does Not Rotate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257 1.3.2 The Motor Does Not Rotate at the Commanded Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 9Table of Contents B–65160E/02 C.4 SPINDLE MOTOR α L SERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 383 C.5 SPINDLE MOTOR α HV SERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 385
