AC Spindle Motor Alpha Series Parameter manual Page 79

Parameter manual
FANUC AC SPINDLE MOTOR a series
2. FUNCTION EXPLANATION
B–65160E/02
70
Parameter No.
0 15 15i 16i/16
Description
6141 #2 3321 #2 3177 #3 4177 #3 Mounting direction of the magnetic sensor
6140 #0 3320 #0 3176 #0 4176 #0 Direction of spindle and motor rotation
6143 #0 3323 #0 3179 #0 4179 #0 Selection of a spindle orientation function; position coder method or
magnetic sensor method
(To select magnetic sensor method spindle orientation, specify 1.)
6143
#3, 2
3323
#3, 2
3179
#3, #2
4179
#3, 2
Direction of rotation in spindle orientation
6172
6173
3352
3353
3208
3209
4208
4209
Velocity loop proportional gain for orientation
(A parameter is selected by the CTH1A input signal.)
6177 3357 3213 4213 Velocity loop integral gain for orientation
6180
6181
3360
3361
3216
3217
4216
4217
Spindle–to–motor gear ratio
(A parameter is selected by the CTH1A input signal.)
6182
6183
3362
3363
3218
3219
4218
4219
Position gain for orientation
(A parameter is selected by the CTH1A input signal.)
6184 3364 3220 4220 Rate of a change in the position gain upon completion of spindle
orientation
6190 3370 3226 4226 Detection level for the spindle orientation completion signal
6191 3371 3227 4227 Motor speed limit for spindle orientation
6192 3372 3228 4228 Spindle orientation stop position shift
6193 3373 3229 4229 MS signal constant
6194 3374 3230 4230 MS signal gain adjustment
6201 3381 3237 4237 Motor voltage for spindle orientation
6169 3349 3205 4205 Spindle orientation speed
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
ROTA
6500 3000 3000 4000
6640 3140
1st–
2nd–
Standard setting: 0 0 0 0 0 0 0 0
ROTA: Indicates the relationship between the rotation directions of spindle and
spindle motor.
0: Rotates the spindle and spindle motor in the same direction.
1: Rotates the spindle and spindle motor in the reverse direction.
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
MGSEN
6501 3001 3001 4001
6641 3141
1st–
2nd–
MGSEN:Indicates the mounting direction of magnetic sensor.
0: Rotates the motor and magnetic sensor in the same direction.
1: Rotates the motor and magnetic sensor in the reverse direction.
Parameters on the sub
spindle side of spindle
switching control
2.3.4
Ditail of Parameter
Previous page
Next page
