FANUC AC SPINDLE MOTOR a series

3. EXPLANATION OF

PARAMETERS

B–65160E/02

238

16i/1615 15i0

Command multiplier for spindle orientation by a position coder

(MAIN side)

6292 3472 3328 4328

6472 3692

Command multiplier for spindle orientation by a position coder

(SUB side)

6293 3473 3329 4329

6473 3693

Data unit :

Data range : 0 to 32767

Standard setting : 0

Set a command multiplier for the spindle orientation function with an

externally set incremental command.

When 0 is set in these parameters, 1 is assumed to have been specified.

To use spindle speed control, set 4096 in these parameters.

16i/1615 15i0

Motor excitation delay for spindle orientation (MAIN side)

6294 3474 3330 4330

6474 3694

Motor excitation delay for spindle orientation (SUB side)

6295 3475 3331 4331

6475 3695

Data unit : 1 msec

Data range : 0 to 32767

Standard setting : 0

When 0 is set in these parameters, a specification of 50 msec is

assumed. The setting of these parameters is valid only when the speed

is within the range from the speed zero detection level (SST = 0) to the

orientation speed.

If overshoot occurs when the spindle stops during spindle orientation

from a speed within the range from the speed zero detection level (SST

= 0) to the orientation speed, overshoot can be suppressed by setting a

value greater than 50 msec.

16i/1615 15i0

Arbitrary number of speed detector pulses (MAIN side)

6298 3478 3334 4334

6478 3698

Arbitrary number of speed detector pulses (SUB side)

6299 3479 3335 4335

6479 3699

Data unit : 1 l/rev (number of speed detector teeth)

Data range : 0, 32 to 1024

Standard setting : 0

Set these parameters when the number of teeth of the speed detector

mounted onto the motor is other than 64, 128, 256, 512, 192, or 384.

When 0 is set in these parameters, the settings of bits 2, 1, 0 (VDT3, 2,

1) of parameter No. 4011 and bits 2, 1, 0 (VDT3, 2, 1) of parameter

No. 4187 are assumed, respectively.

16i/1615 15i0

Data unit : 1 min

–1

(10 min

–1

when bit 2 (SPDUNT) of

parameter No. 4006 is set to 1)
