FANUC AC SPINDLE MOTOR a series
2. FUNCTION EXPLANATION
B–65160E/02
154
Parameter No.
0
Main spindle
side/
sub spindle
side
Description
16i/1615i
15
1st
spindle
Main spindle
side/
sub spindle
side
Description
16i/1615i
2nd
spindle
1st
spindle
2nd
spindle
6513 #6 to 2 6653 #6 to 2 3013 #6 to 2 3153 #6 to 2 3013 #6 to 2 4013 #6 to 2
Current dead
zone data
6610 6750 3110 3250 3110 4110
Current
conversion
constant
6612 6752 3112 3252 3112 4112
Current
prediction
constant
Main spindle
side
6524 6664 3024 3164 3024 4024
Speed zero
detection
level
6153 #6 to 2 6333 #6 to 2 3333 #6 to 2 3553 #6 to 2 3189 #6 to 2 4189 #6 to 2
Current dead
zone data
6228 6408 3408 3628 3264 4264
Current
conversion
constant
6230 6410 3410 3630 3266 4266
Current
prediction
constant
Sub spindle
side
6163 6343 3343 3563 3199 4199
Speed zero
detection
level
(1) Automatic spindle parameter initialization
1. Set the model code for the motor to be used for automatic
parameter initialization.
When a motor has no corresponding model code, set the code for
a similar model, or set model code 0.
Parameter No.
1st spindle 2nd spindle
CNC
Main
spindle
side
Sub
spindle
side
Main
spindle
side
Sub
spindle
side
Settings
0 6633 6273 6773 6453
15 3133 3453 3273 3673
15i 3133 3309 3133 3309
Model code
16i/16 4133 4309 4133 4309
2.8.4
Parameter Setting
Procedure
