FANUC AC SPINDLE MOTOR aC series
291
16i/16
15
15i
0
Motor speed limit value on orientation
6576 3076 3076 4076
6716 3216
Data unit : 1%
Data range : 0 to 100
Standard setting : 33
This data is used to set the motor speed value on orientation.
Orientation speed (min
–1
)
= Position gain (sec
–1
) gear ratio 60 (setting data) /100
16i/16
15
15i
0
Orientation stop position shift value
6577 3077 3077 4077
6717 3217
Data unit : 1 pulse
Data range : – 4095 to 4095
Standard setting : 0
In position coder method orientation, set this data to shift stop position.
Spindle is shift number of setting pulse in CCW direction, and stop by
+data.
16i/16
15
15i
0
In the torque limit (TLM=1), the timer setting that the change the motor
speed data between estimated speed and motor speed calculated from
position coder signal ( 9D12 series only )
6578 3078 3078 4078
6718 3218
Data unit : sec
Data range : 0 to 500
Standard setting : 0
When the spindle has the gear change mechanism, please refer to our
recommended gear change sequence for smooth gear change. In our
recommended sequence, this parameter is used.
16i/16
15
15i
0
Position gain switching speed preset value
6579 3079 3079 4079
6719 3219
Data unit : 1 min
–1
Data range : 0 to 32767
Standard setting : 0
This parameter is used for the position gain polygonal line function in the
position coder method spindle orientation.
This function doubles the position gain in low speed range.
