AC Spindle Motor Alpha Series Parameter manual Page 192

Parameter manual
B–65160E/02
3. EXPLANATION OF
PARAMETERS
FANUC AC SPINDLE MOTOR a series
183
16i/1615 15i0
Speed detecting level
6523 3023 3023 4023
6663 3163
Data unit : 0.1%
Data range : 0 to 1000 (0 to 100%)
Standard setting : 30 (3%)
This data is used to set the detecting range of speed detecting signal
(SDTA).
When the motor speed reaches (setting data/10) % or less of maximum
speed, the bit of speed arrival signal (SDTA) is set to ”1”.
16i/1615 15i0
Speed zero detecting level
6524 3024 3024 4024
6664 3164
Data unit : 0.01%
Data range : 0 to 10000 (0 to 100%)
Standard setting : 75 (0.75%)
This data is used to set the detecting range of speed zero detection signal
(SSTA).
When the motor speed reaches (setting data/100)% or less of maximum
speed, the bit of speed zero detection signal (SSTA) is set to ”1”.
16i/1615 15i0
Setting of torque limit value
6525 3025 3025 4025
6665 3165
Data unit : 1%
Data range : 0 to 100 (0 to 100%)
Standard setting : 50 (50%)
This data is used to set the torque limit value for maximum output torque
when the torque limit command HIGH (TLMHA) or torque limit
command LOW (TLMLA) is commanded.
Data represents limiting values when the maximum torque is assumed to
be 100%.
Torque limit
command LOW
(TLMLA)
Torque limit
command HIGH
(TLMHA)
Details
0 0 No torque limitation exists.
0 1
Torque limited to the setting value
of this parameter.
1 0
Torque limited to approximately
1 1
half as compared with that of this
parameter.
