FANUC AC SPINDLE MOTOR a series

2. FUNCTION EXPLANATION

B–65160E/02

140

The following describes an example of determining the shift amount for

phase synchronization in synchronous control of the spindle phase.

1. Apply synchronous control of the spindle phase by setting the

following:

D SFR = 1 (SRV = 1) for the 1st and 2nd spindles

: M03

D Spindle synchronous speed command = 0 rpm

:S0

D For the 1st and 2nd spindles, set 0 in the parameter for the

shift amount for spindle phase synchronization control.

2. After establishing spindle phase synchronization, set SFR for the

2nd spindle to 0 (to deactivate the motor).

The 2nd spindle must be rotated manually because the power to

its motor is turned off.

3. Manually rotate the 2nd spindle to the next position where

spindle phase synchronization is to be established.

On the diagnosis screen indicating the number of error pulses

between the two spindles, check the number of error pulses

output between the first position where spindle phase

synchronization was established to the next position where

spindle phase synchronization is to be established.

This value serves as data to be set in the parameter for the shift

amount used for spindle phase synchronization.

4. Set the number of pulses, determined as above, in the parameter

for specifying a shift amount for spindle phase synchronization

for the 2nd spindle.

In general, set 0 in the parameter for the shift amount for spindle

phase synchronization for the 1st spindle.

5. After cancelling the spindle synchronization command, perform

another spindle phase synchronization operation, according to

the following settings, to check that phase synchronization has

been established as expected:

D SFR = 1 (SRV = 1) for the 1st and 2nd spindles

: M03

D Spindle synchronous speed command = 0 min

–1

:S0

2.6.6

Specifying a Shift

Amount for Spindle

Phase Synchronization

Control
