AC Spindle Motor Alpha Series Parameter manual Page 219

Parameter manual
FANUC AC SPINDLE MOTOR a series
3. EXPLANATION OF
PARAMETERS
B–65160E/02
210
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
SVMDRT
6142 3322 3178 4178
6322 3542
Standard setting: 0 0 0 0 0 0 0 0
SVMDRT:
Rotation direction signal (SFR/SRV) function setting when in servo
mode (rigid tap/spindle positioning)
0: Rotation direction function present
With a + motion command, spindle rotation is CCW when SFR=1 spindle
rotation is CW when SRV=1
1: Rotation direction function absent
With a + motion command, spindle rotation is CCW when SFR=1 or
SRV=1
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
PCPL2 PCPL1 PCPL0 PCTYPE DIRCT2 DIRCT1 PCCNCTPCMGSL
6143 3323 3179 4179
6323 3543
Standard setting: 0 0 0 0 0 0 0 0
PCMGSL:
Selection of position coder method/magnetic sensor method spindle
orientation
0: Position coder method spindle orientation function
1: Magnetic sensor method spindle orientation function
PCCNCT:
Specifies whether a MZ sensor or BZ sensor (built–in motor) in a
motor is used.
0: Not used.
1: Used.
Set this bit to 1 when a MZ sensor (built–in sensor) in a motor is used.
Also, set this bit to 1 when a built–in motor’s BZ sensor (built–in
sensor) is used.
DIRCT2–DIRCT1:
Setting of rotation direction at spindle orientation
DIRCT2 DIRCT1 Rotation direction at spindle orientation
0 0 By rotation direction immediately before
0 1 By rotation direction immediately before
1 0
CCW (counterclockwise direction) looking from shaft of
motor
1 1 CW (clockwise direction) looking from shaft of motor
PCPL1, PCPL2, PCPL0, PCTYPE:
Set a position coder signal.
PCPL2 PCPL1 PCPL0 PCTYPE MZ sensor,
BZ sensor
(Built–in sensor)
Others
0 0 0 0 256 l/rev (f103) Position coder
0 0 0 1 128 l/rev (f52) ––
