2. FUNCTION EXPLANATION
FANUC AC SPINDLE MOTOR a series
47
DIRCT2-DIRCT1:
Setting of rotation direction at spindle orientation
DIRCT2 DIRCT1 Rotation direction at spindle orientation
0 0 By rotation direction immediately before
(It is CCW at the power on.)
0 1 By rotation direction immediately before
(It is CW at the power on.)
1 0 CCW (counterclockwise) direction looking from
shaft of motor
1 1 CW (clockwise) direction looking from shaft of motor
When ”By rotation direction immediately before” is set, ”rotation
direction immediately before” is determined to be the direction of rotation
performed at a level higher than the zero speed detection level (Output
signal SST = 0).
PCMGSL:
Selects the type of orientation.
Set this bit to 0 (orientation by a position coder).
PCPL2, PCPL1, PCPL0, PCTYPE:
Set a position coder signal.
Set these bits according to the type of detector being used. Set these bits
to ”0,0,0,0” when using a position coder.
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
RFTYPE EXTRF
6504 3004 3004 4004
6644 3144
1st–
2nd–
EXTRF: Specifies whether an external one–rotation signal is used.
0: Not used.
1: Used.
RFTYPE: Specifies whether to invert the external one–turn signal.
0: The final signal is to be inverted.
1: The final signal is not to be inverted.
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
PCGEAR
6509 3009 3009 4009
6649 3149
1st–
2nd–
PCGEAR:
Setting of the spindle orientation with a reference switch. To enable
use of the reference switch signal, set this bit to 1.
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
NRROEN RFCHK4
6517 3017 3017 4017
6657 3157
1st–
2nd–
Standard setting: 0 0 0 0 0 0 0 0
RFCHK4:
Specifies whether to use the position coder 1- rotation signal detection
function in normal rotation.
0: Does not detect the 1-rotation signal in normal rotation.
1: Detects the 1-rotation signal in normal rotation.
