FANUC AC SPINDLE MOTOR a series

2. FUNCTION EXPLANATION

B–65160E/02

A. Check that the system is ready for normal operation.

B. Prepare and check the ladder program for performing magnetic sensor method orientation.

B. (Refer to the Descriptions (B–65162E).)

C. Set the necessary parameters for magnetic sensor method orientation. (See Section 2.3.3.)

E. Check the connection and feedback signal of the magnetic sensor.

F. Check that orientation is possible.

D. Set the necessary parameters for the magnetic sensor. (See Section 2.3.3.)

B. MS signal constant, MS signal gain, mounting direction of the magnetic sensor

G. Set and check the direction of orientation.

D Set the direction of rotation for orientation.

H. Adjust the orientation stop position.

D Detection level for the orientation completion signal

D Orientation stop position shift

I. Adjust the orientation speed.

D Position gain for orientation

D Motor speed limit ratio for orientation

D Orientation speed

J. Adjust the orientation stop–time.

B. (Eliminate any overshoot, and ensure rigidity in the stop state.)

D Position gain for orientation

D Velocity loop proportional gain for orientation

D Velocity loop integral gain for orientation

D Setting of motor voltage for orientation

D Rate of a change in the position gain when orientation is stopped

K. Check ATC operation.

2.3.1

Start–up Procedure
